SRP 540 W – 555 W

SERIES

WARRANTY
QUALITY SYSTEM
ISO9001 / ISO14001 / ISO45001

KEY FEATURES

INSURANCE
PRODUCT CERTIFICATION

Less mismatch to get more power

Ideal choice for utility and commercial scale projects
by reduced BoS and improved ROI
Less power loss by minimizing the shading impact

3 times EL test to ensure best quality
Competitive low light performance

Outstanding reliability proven by PVEL for
stringent environment condition:
Sand, acid, salt and hail stones
2400 Pa wind load and 5400 Pa snow load
Anti-PID

Electrical Characteristics

External Dimensions
Pmax Temperature Coefficient
Voc Temperature Coefficient
Isc Temperature Coefficient
Operating Temperature
Nominal Operating Cell Temperature(NOCT)

Weight
Solar Cells
Front Glass
Frame
Junction Box
Output Cables
Mechanical Load

2278x1134x35 mm
27.0 kg
PERC Mono (144pcs)
3.2mm AR coating tempered glass, low iron
Anodized aluminium alloy
IP68, 3 diodes

4.0mm2
, 250mm(+)/350mm(-) or Customized Length
Front side 5400Pa/ Rear side 2400Pa

Packing Configuration

Pieces per Pallet
Pallets per Container
Pieces per Container
Container 20’GP
4
140
31+4*
2278x1134x35 mm

STC: lrradiance 1000 W/m2 module temperature 25°C AM=1.5
Power measurement tolerance: +/-3%

(0, +4.99W)
1500V DC
25 A

Maximum Power at STC (Pmp)
Open Circuit Voltage (Voc)
Short Circuit Current (Isc)
Maximum Power Voltage (Vmp)
Maximum Power Current (Imp)
Module Efficiency at STC(%)
Power Tolerance
Maximum System Voltage
Maximum Series Fuse Rating
Module Type

40’HQ
20
620
31

I-V Curve

+86-519-68788166

2022V2.0 2

* 31+4 pieces per pallet is the special package which only suits for container transport.
For details, please consult SERAPHIM.

SRP-540-BMA-HV SRP-545-BMA-HV SRP-555-BMA-HV
STC NOCT STC NOCT STC NOCT
540
49.50
13.81
41.55
13.00
406
46.18
11.16
38.39
10.59
20.90
545
49.60
13.90
41.80
13.04
409
46.32
11.23
38.41
10.65
21.10

555
49.80
14.10
42.31
13.12
418
46.50
11.41
38.68
10.81
21.48
SRP-550-BMA-HV
STC NOCT
550
49.70
14.00
42.05
13.08
414
46.40
11.32
38.58
10.73
21.29
